Shenzhen Hanway Industrial Digital Equipment Co., Ltd

Hanway Glory1604 Industrial digital corrugated cardboard inkjet printer

● Glory 1604: 12700*5590*2300mm (41.6F*18.3F*7.5F). ● Glory 1604 + Stacker: 19560*5590*2300mm (64.1F*18.3F*7.5F). ● Glory 1604 + Tunnel Dryer + Varnish + Stacker: 30635*5590*2300mm (100.5F*18.3F*7.5F). ● Linear speed up to 490 feet/min. ● Types:Wide range of corrugated boards(coated,white,Kraft etc.)

Shenzhen Hanway Industrial Digital Equipment Co., Ltd

Hanway Highjet2500A High-Speed

● Equipment Dimension:3800*4800*1900mm(Feeding direction:L*W*H). ● Type of Ink:Environmentally friendly water-based ink. ● Ink Color:C/M/Y/K. ● Brand of Nozzle:Kyocera. ● Max.Printing Width:2500mm. ● Max.Printing Accuracy:600×1200dpi. ● Thickness Range of Medium Printed:1-20mm. ● Applicable Medium for Printing:Corrugated cardboard.

Shenzhen Hanway Industrial Digital Equipment Co., Ltd

Hanway HighJet2500B High-Speed

● Applications:Corrugated board,Retail ready display,Event graphics,light boxes,etc. ● Ink Type:Han FullColor? Water-based Ink. ● Print head:Kyocera KJ4B dual channel. ● Dryer:IR and air(Optional). ● Ink Supply:Automatic. ● Print head Configuration:Standard dual channel 4 color(CMYK),4 print heads,maximum 8 print heads.Print head coverage 224mm in length.

Shenzhen Wonder Printing System Co., ltd.

WD200 Industrial Single Pass Printer

WD200 Industrial Single Pass Digital Corrugated Printer WD200(WD200-24A/32A/48A/64A) Product Features Fast speed: the fastest production speed can be 0.9m/s with 360*180dpi, 0.6m/s with 360*360dpi, 0 3m/s with360*720dpi. Version costs: traditional printing system need to produce flexor, takes time and money. but WD200environmentally printing system do not need it and use inkjet printing technology. Environmentally: the traditional printing system need washing machine, produce large amounts of sewage,and produce large amounts of waste flexor, pollute the environment when replace the varieties. The WD200environmentally printing system use 4-source color inkjet printing technology, won’t cause these problems. Labor: the traditional printing system, from the plate to the printing demands worker with high request and number,the process is cumbersome, time-consuming and labor-intensive, reducing production efficiency . WD200 environmentally printing system use computer plate-making, computer palette and computer save,simple operation, printing on-demand, saving time and labor, high production efficiency.

Shenzhen Hanway Industrial Digital Equipment Co., Ltd

Hanway Glory2504 Four Color Single Pass for Corrugated Press

● Cost Effective. ● Meet the Demand of Industrial Production. ● Stability and Safety. ● Achieved integrated molding. ● Maximize Customers’ Satisfaction. ● Boosts the Innovation of Business Models.

Shenzhen Wonder Printing System Co., ltd.

WONDERJET WDR200 Single Pass

WDR200 Industrial Single Pass Corrugated Carton four-color Digital Inkjet Printing Machine 600*200dpi, max 2.2m/second; 600*300dpi, max 1.6m/second; 600*600dpi, max 0.8m/second;

Shenzhen Wonder Printing System Co., ltd.

WD 250-8A/12A Digital

1.Without plate, without cleaning, Convenient, Environmental; 2.Printhead constant temperature system, can effectively overcome low; 3.Temperature environment; 4.Using stronger servo motor and high precision reducer. Higher precision; 5.Faster speed, More stable performance; 6.Using 6 grade super high precision gear and high precision cylindrical; 7.grinding roller, drive more accurately;

Shenzhen Hanway Industrial Digital Equipment Co., Ltd

Hanway Glory 1604 Single-Pass corrugated Inkjet press

● Industrial robust design with the fastest production speed up to 150m/min and High Flexo-like print quality. ● Digital printing technology brings you the experience of instantaneous response and seamless switch among multiple short-run orders. ● Applicable to all kinds of substrates including Kraft, Mottled White and Coated White. ● Aqua-base ink jet provides the low printing cost and supports the wide range of packaging applications. ● 24/7 technical support & service.

Shenzhen Wonder Printing System Co., ltd.

WONDERJET WDUV250-12A Digital UV Printing Machine

WDUV250-12A Mutial five-color UV Digital Inkjet Printing Machine for cardboards and building materials Printing speed: WDUV250-12A max can be 230㎡/H

Shenzhen Wonder Printing System Co., ltd.

WONDERJET WDUV250-24A UV Digital Inkjet Printing Machine

WDUV250-24A Mutial five-color UV Digital Inkjet Printing Machine for cardboards and building materials Printing speed: WDUV250-12A max can be 230㎡/H WDUV250-24A max can be 460㎡/H

How to make wise investment in corrugated digital printing system?

Why we suggest to invest in a complete set of corrugated digital printing system rather than a single digital printing press? It is simply because the development speed of computer Internet era is accelerating, the competition of packaging and printing is becoming more and more fierce, a single machine is unable to survive in such fierce competition, however a complete set of corrugated digital printing system can allow packaging enterprises to constantly improve the whole production chain, to provide more competitive products.The following issues should be noticed when investing in corrugated digital printing system:1. Evaluate the business structure.Enterprises need to determine the investment direction according to their own business structure and development goals. Each enterprise has its unique demand configuration to avoid homogenization and price competition. For example, the current rapid development of e-commerce has brought new directions for investment in corrugated packaging. In order to increase sales and keep returned customers, sellers usually provide personalized packaging services. These orders are all and complex, if enterprise has a system that automatically figure out personalized all batch customization, it can win a lot of stable customers. Less is more, that’s the way to realize rapid profitability.2.Compare product performance.Many enterprises are always hesitant in choosing products after setting goals, therefore missing a good opportunity. In fact, enterprises can consider the stability of suppliers' products, printing quality, price, cost of consumables, cost of manpower training, after-sales service and environmental factors. After-sales service is very important and necessary. Especially in the preliminary stage of corrugated digital printing, enterprises choose suppliers where close to their own factories, so that any problem can be dealt with quickly and timely, and downtime costs can be avoided.3.Consider the return on investment ratio Only profit can make sustainable development for enterprises. Corrugated digital printing equipment can be selected from tens of thousands to tens of millions of price range. How to realize quick return on investment is a problem that enterprises must face. Based on the current development of corrugated digital printing and the historical performance of commercial printing, enterprises can start to invest in corrugated digital printing equipment.Six technical points to consider when choosing a digital printer1.Printed material adaptabilityDue to the special nature of corrugated paper, the digital printing machine needs to be flexible in the range of thickness, ink must be suitable for a variety of coated surface, and ink volume can be set according to different corrugated materials.2. Printing width The size of the packing box determines the format of the digital printing machine. The existing corrugated digital printing machine can meet most sizes, and the width of the corrugated digital printing machine is more than 1 meter, which is the minimum requirement.3.Printing speed Speed is very helpful for enterprises to arrange production flexibly and improve production capacity. Most professional corrugated digital printing machines can reach speeds of tens of meters or more than 100 meters per minute.4.Nozzle technologyIn selection of inkjet nozzle technology is also a key premise. Because dust will be greatly collected in the printing process, the nozzle performance and maintenance requirements are very strict.5.Ink From the perspective of applicability, UV ink has a wider range of printed adaptability, but post-printing drying and environmental requirements are higher, which need professional ventilation system. Water- based ink has a good environmental performance, but the printed adaptability requirements are also higher.6.Post -press-finishingThe treatment after printing is related to the final forming effect.Whether it can be scoring/die cutting? Whether it can be integrated with existing related back-end equipment relates to the overall investment cost of the enterprise.

1448 0

The development status of digital printing in Corrugated packaging industry

 With more and more customized orders and short plate orders, digital printing is gaining more and more attention by the packaging industry. What the developing stage of the digital printing ? What are the advantages and disadvantages of digital printing?1.Three grades of corrugated digital printing pressWith the continuous innovation of digital printing technology, commercial digital printing equipment has been expanding to support thicker cardboard. However, the development speed of digital printing press special for corrugated paper is still far behind that of the commercial field, which is more at the beginning level. Professional level and industrial level need more efforts in light of research and development.1).Beginning levelWe are often heard of digital printing press for corrugated paper, the common one is versatile digital printing press. In fact, many all equipment suppliers purchase domestic or foreign nozzle, and inkjet imaging, then design a set of platform system and integrated software output system, in this way, a versatile digital printing press at beginning level is finished. There are tens of millions manufactures, and the price ranges from tens of thousands of yuan to hundreds of thousands, investment threshold is rather low. The machine not only can print on corrugated paper, but also on other materials such as plastic, metal, glass and ceramic etc. What a versatile one!However, such equipment has many shortcomings, such as unstable operation, difficult color control, limited production capacity, low degree of automation, which is heavily relying on the experience of operators.2).Professional levelCompared to the entry level, it has been greatly improved, the speed is faster, basically, it can run stably at about 100 m/min. It has specialized software system, the printing quality, degree of automation and stability have been significantly improved. Integrated with foreign brand nozzle, dedicated to corrugated paper printing. There is a wide range of choices in domestic and foreign brands, the price differs a lot, and the late use of cost-sharing is more controllable.3).Industrial levelThe first industrial corrugated digital printing press was manufactured by kodak and Sun automation group, and then HP launched Scitex series. EFI also launched the C18000 corrugated digital printing press in 2016. This kind of rapid equipment based on UV and water - based ink - jet technology has the performance of good quality, fast speed, high productivity, and wide compatibility. The degree of automation and intelligence is relatively high, one-time cost investment is also high. It is very suitable for large corrugated packaging enterprises.2.Three basic categories of digital printing equipmentAt present, digital printing press in corrugated packaging industry can be divided into three types: partial digital printing, flat-sheet digital printing, web-fed digital printing.1). Partial digital printingPartial digital printing is a combination of traditional printing and digital printing equipment. Partial random graphic printing can be realized at a relatively low cost.2). Flat-sheet digital printingFlat-sheet digital printing press targets the traditional water-printing or offset printing press.Generally, there are fixed nozzle and sliding nozzle. Printing width is usually large, the feature of mixing the ink without changing the plate has attracted a lot of corrugated packaging enterprises.3).Web-fed digital printing The main market for web digital printing is for large volume orders involving traditional offset and water-printing, as well as flexographic pre-printing.Discussion on the operation of digital printing equipment1).Equipment costAt present, the cost of digital printing equipment is generally high, the main reasons are as follows:● It is not a very long time for digital printing technology being used in corrugated packaging industry, therefore, the equipment, technology research and development costs are relatively high.● The market for digital printing equipment is in its infancy with limited sales volumes.2). Maintenance costThe maintenance cost of nozzle should be dominant in the whole range. The nozzle is the most precise and core part of the digital printing press. The ink, use frequency and use environment will all have impact on its service life and quality, as a result, the cost of cleaning or replacing the nozzle is high. Besides, the patented technical protection and production accuracy of nozzle also lead to high cost.3). Production costThe current popular digital printing equipment in corrugated packaging industry is mainly for inkjet, high-speed and high pressure inkjeting is the key to ensure the production speed and quality. So the ink pressure is essential. If the production continuity is not high or the nozzle is not stable, it will lead to a rise in ink consumption, and the current digital printing equipment ink cost is generally more than ten times the traditional printing ink, or even higher.4). Production efficiencyAt present, most of the digital printing equipment is positioned as customized products. The reason is that many people hold the misunderstanding of which the biggest advantage of digital printing is complete customization. As a result, the production efficiency of some current digital printing equipment is low and the product price is too high to fully expand the market share.In fact, under the current technical conditions, the real key to digital printing that is different from traditional printing is variable graphic printing, rather than variable cutting.5).Quality stabilityDue to the short time for digital printing equipment to enter the corrugated packaging industry, the acceptance of digital printing technology and corrugated market needs time and space. At present, the accuracy of inkjet digital printing could basically meet the market demand. But the stability of production quality needs to be further improved.

1054 0

How to Maintain and Use Paper Feeding Roller

At present, most printing presses adopt the leading edge paper feeding. An indispensable part of the leading edge paper feeding is the paper feeding rubber roll. The advantage of  paper feeding roller is that it can transfer the paper oothly to the carrying roll, the main of paper feeding roll is to transfer.Friction will be produced in the process of feeding paper, if you do not pay attention to the maintenance during the process, the paper feeding roll will need to be replaced, not only  to cause cost waste, but also some other production loss.1.Abrasion is the “biggest killer” of paper feeding rollNow there are more and more manufacturers produce paper feeding roll, the service life of each and every is not the same, feeding roll loss is mainly caused by wear and tear, because paper feeding will produce friction, the circumference of rubber roll after a long time use will be changed, and it needs to be replaced after a certain period of time. 2.Paper feeding roll abrasion will cause mass production wasteLet's do a math: take the configuration of model 1200 as example, if one paper feeding roll is $11, 64 rolls in total for the paper feeding unit, so the total cost is : $11*64pcs = $704, if the maintenance is not well, paper feeding roll will be replaced in half a year, then the spending in one year on the paper feeding roll will be$1,408.But this is not the most important, if the paper feeding roll wear, it will cause slotting shift, color process inaccuracy, printing askew and a series of production losses, not only resulting in production waste, but human cost waste. 3.How to maintain and use the paper feeding roller1) One of the main reasons for paper feeding roll wear is that the paper scraps get stuck between the roll and the supporter, so the position where paper scraps stuck will be immediately worn out when running at high speed. So when foreign matter is found in the front of paper feeding roll, it must be promptly cleaned.2) After a period of time, switch the paper feeding roll, that is to switch the roll at both sides to the middle, be sure to make it on the same level, only in a flat surface, can reduce paper feeding roll wear.3) Paper feeding roll should be regularly cleaned and maintained, alcohol can be used. Do not use toluene for cleaning. After cleaning the paper feeding roll, it can work well, and  friction of the paper feeding roll will be increased as well.4) Paper feeding roll rotation with an uneven speed is also a main reason for wear, so we must repair and maintain paper feeding roll when they are rotating slowly.Special reminder: The operator of the printing press should often pay attention to the cleanliness of the paper feeding roll, because the damage of the paper feeding roll directly affects the precision of printing tranission, and sometimes feeding askew may be caused by a damaged paper feeding roll .

1310 0

Hanglory USA hosted an Open House for "Single Pass Corrugated Press"

Hanglory USA conducted its North America open house from June 18th to 22nd that was attended by various potential customers. Hanglory USA partnered with Packaging Solution & Logistics (PSL) for Glory1604 single-pass digital corrugated press of which printing speed will reach to 492feet/min and solutions demonstration on PSL’s new factory in St. Antonio, Texas.

1741

Hanglory USA to be a World-Class Provider of Digital Ink Jet Printing Solutions

TAPPI Corrugated Week 2018 has successfully conducted at the Indiana convention center from September 24th to 27th 2018 in North America. It is a gateway to industry trends, innovations, new products and services and so much more of the corrugated packaging industry. Hanglory USA has been invited as an exhibitor. Glory1604 aqua-based ink solutions and the colorful samples attracted various customers and packaging industry experts

1737

Digital Print for Packaging Market to 2022– Strong Growth Led by Corrugated Inkjet

Digital print for packaging is worth $13.2 billion in 2017, and will climb to $23.2 billion in 2022, according to the latest exclusive research from Smithers Pira. As such it represents a key growth area for the print industry, as well as opening new market opportunities for packaging converters and their brand customers.

1403

Premium Related Products

● Glory 1604: 12700*5590*2300mm (41.6F*18.3F*7.5F). ● Glory 1604 + Stacker: 19560*5590*2300mm (64.1F*18.3F*7.5F). ● Glory 1604 + Tunnel Dryer + Varnish + Stacker: 30635*5590*2300mm (100.5F*18.3F*7.5F). ● Linear speed up to 490 feet/min. ● Types:Wide range of corrugated boards(coated,white,Kraft etc.)

WD200 Industrial Single Pass Digital Corrugated Printer WD200(WD200-24A/32A/48A/64A) Product Features Fast speed: the fastest production speed can be 0.9m/s with 360*180dpi, 0.6m/s with 360*360dpi, 0 3m/s with360*720dpi. Version costs: traditional printing system need to produce flexor, takes time and money. but WD200environmentally printing system do not need it and use inkjet printing technology. Environmentally: the traditional printing system need washing machine, produce large amounts of sewage,and produce large amounts of waste flexor, pollute the environment when replace the varieties. The WD200environmentally printing system use 4-source color inkjet printing technology, won’t cause these problems. Labor: the traditional printing system, from the plate to the printing demands worker with high request and number,the process is cumbersome, time-consuming and labor-intensive, reducing production efficiency . WD200 environmentally printing system use computer plate-making, computer palette and computer save,simple operation, printing on-demand, saving time and labor, high production efficiency.

● Equipment Dimension:3800*4800*1900mm(Feeding direction:L*W*H). ● Type of Ink:Environmentally friendly water-based ink. ● Ink Color:C/M/Y/K. ● Brand of Nozzle:Kyocera. ● Max.Printing Width:2500mm. ● Max.Printing Accuracy:600×1200dpi. ● Thickness Range of Medium Printed:1-20mm. ● Applicable Medium for Printing:Corrugated cardboard.

Fast speed: max material moving speed can reach 0.9m per second, it means the yields can up to 3600pics with 0.7m length cartons per hour, fairly with the traditional chain machine.

● Applications:Corrugated board,Retail ready display,Event graphics,light boxes,etc. ● Ink Type:Han FullColor? Water-based Ink. ● Print head:Kyocera KJ4B dual channel. ● Dryer:IR and air(Optional). ● Ink Supply:Automatic. ● Print head Configuration:Standard dual channel 4 color(CMYK),4 print heads,maximum 8 print heads.Print head coverage 224mm in length.

JD-Xquis 2500 is a high-speed digital water-based inkjet printer that is an excellent alternative to traditional water-based printing equipment, using plateless printing technology to achieve high-speed and efficient production. Based on WINDOWS, innovative imaging technology implemented through the D-Print software platform ensures the accuracy and consistency of the colors required by your customers, the color standard adopts the ICC color standard, and the accurate conversion of images through professional RIP software, with the capacity requirements and efficiency you need.
